Electrical Changeover Cam Switch 4P 10A IP65 IEC standard
Product Description
| Brand Name | KRIPAL |
| Model Number | UKT0/3/5 |
| Type | Cam switch |
| Number of poles | 1P,2P,3P,4P |
| Current | 10A,16A,20A,25A,32A,40A,50A,63A,80A,100A |
| Frequency | 50/60Hz |
| Protection | IP65 |
| Material | PA,PC,Copper |
| Standard | IEC/EN 60947-3 |
| Identification | VDE,SEMKO,CE CERTIFICATE,CB TEST REPORT |
| Warranty | One and a half years |
Reference Model
| Current(A) | Rated Voltage(V) | Model |
| 3P | 4P |
| 10 | 230-440V | UKTN0-310/8212 | UKTN0-410/8213 |
| 16 | 230-440V | UKTN0-316/8212 | UKTN0-416/8213 |
| 20 | 230-440V | UKTN0-320/8212 | UKTN0-420/8213 |
| 20 | 230-440V | UKTN3-320/8212 | UKTN3-420/8213 |
| 32 | 230-440V | UKTN3-332/8212 | UKTN3-432/8213 |
| 40 | 230-440V | UKTN3-340/8212 | UKTN3-440/8213 |
| 63 | 230-440V | UKTN5-363/8212 | UKTN5-463/8213 |
| 80 | 230-440V | UKTN5-380/8212 | UKTN5-480/8213 |
| 100 | 230-440V | UKTN5-3100/8212 | UKTN5-4100/8213 |
Proper installation ways
①Surface installation(insulation enclosure assembled)
②Parallel and level installation(fix in front of it)
③Rear installation(fix at the back of it,door linkage or cover linkage)
Product Feature
1.Possibility of multi-combination and safety of touch
Cam switch UKT provide 800 standard contacts combinations,their combination number is almost limitless, not only that,in the switch design process,safety and reliability in the first place,such as:equipped with the cover of the terminal in the line with VDE0106,to ensure the safety of the touch.
2.Comprehensive: according to the classification of power capacity, can provide the most economical solution for different projects; There are various installation methods of nameplates, which can flexibly meet the needs of specific applications.
3.Flexible switch functions
On/off switch: can be reliably used in lighting equipment heating equipment and motor, can also be directly on/off motor (AC-3), its high on/off ability to ensure frequent on and off the reliability of the work.
4.Control switch: Used to control the current loop. It simplifies the process of sending instructions from a central control position. For example, starting a specified process from a central control room saves time and makes the production process clear.
Operating application
①Motor star-delta starting,communication or no commutation,with or without contactor interlock circuit.
②Motor(multi-tap winding)rev switching,speed of rotation for2,3 or 4 steps,commutation or no commutation.
③Power supply switching or load switching.
④Starting of AC motor(for single-phase power supply with capacitor)
⑤Control of stepping,suitable for any loads,with or without “O”position.
⑥Ammeter or voltmeter switching among three-phase circuits.
⑦Manual/auto selection.
Packaging & Delivery
| Lead Time | Normally 20 days after received your fund, but mostly depends on your quantity |
| Leading Port | Ningbo or Shanghai by sea or by air. If any other loading port please kindly advise and the extra inland transportation freight will be added accordingly. |
| Trade Term | EXW, FOB, CIF as customer need |
| Payment Term | T/T 30% as deposit,and 70% before delivery. |
| Packaging | Neutral carton, or according to customer requirements |
| Shipping | By Air, by sea, by express |
FAQ
Q:Are your manufacturer and do you have experience?
A:We are manufacturer with more than 30 years experience.
Q:Is sample available and free?
A:Small qty of samples is available and free.But the charge of freight should be paid.
Q:Do you offer OEM service?
A:Yes,we have been providing OEM/ODM service to global manufacturers and suppliers for many years.
Q:How many employees do you have?
A:We have more than 500 employees now,with in-house R&D teem.
Q: How do you make our business long-term and good relationship?
A: 1.We keep good quality and competitive price to ensure our customers benefit;
2.We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
Our company
Zhejiang kripal Electric Co., Ltd. was founded in 1992, and now has two production bases, Yueqing in Wenzhou and Xianju in Taizhou. The company has more than 500 employees, including over 10 senior engineers, 30 professional technicists and 30 senior executives, covering an area of more than 15000 square meters. The company has passed ISO9001 quality system certification, and serves customers with high-quality service, innovative electrical solutions and competitive prices. Therefore, the products are exported to Europe, Australia, America, Africa, Oceania, Southeast Asia, Hong Kong, Macao and Taiwan, with good brand effect in the local area, and won the title of Zhejiang export famous brand enterprise. Our mission is to strive to realize the dream of professional electrical world brand, and strive to improve our company's share in the global market. Welcome to cooperate with kripal to create a better tomorrow.
