25A 3P 230V 440V Waterproof Rotary Isolator Switch IP65 IEC standard

Zhejiang KRIPAL Electric Co., Ltd.
Contact Now

25A 3P 230V 440V Waterproof Rotary Isolator Switch IP65 IEC standard

  • 1
  • 2

Brand Name : KRIPAL

Model Number : UKPN1-325

Certification : VDE,SEMKO,CE CERTIFICATE,CB TEST REPORT

Place of Origin : China

MOQ : 1000 pcs

Price : negotiable

Payment Terms : T/T, L/C, D/P

Supply Ability : 100000 pcs per month

Delivery Time : 20 days and depends on ordering quantity

Packaging Details : Each unit packed in a individual box

Rated current : 25A

Pole : 3P,4P

Voltage : 230-440V

Frequency : 50/60Hz

Material : PC,Copper

Feature : Safety,Low-energy,Easy setup

Contact Now

25A 3P 230V 440V Waterproof Rotary Isolator Switch IEC standard





Product Description



 Brand Name  KRIPAL
 Model Number  UKPN0/1/3/5
 Type  Load Isolation Switch
 Number of poles  3P,4P
 Current  10A,16A,20A,25A,32A,40A,50A,63A,80A,100A,125A,150A
 Frequency  50/60Hz
 Protection  IP65
 Material  PC,Copper
 Standard  IEC/EN 60947-3, AS/NZS 3947
 Identification  VDE,SEMKO,CE CERTIFICATE,CB TEST REPORT
 Warranty  One and a half years
 Advantage  Dustproof,Waterproof,Corrosion protection,Prevent the loss   caused by long-term illumination,Safety,Low-energy,Easy setup



Current(A) Rated Voltage(V) Model
3P 4P
10 230-440V UKPN0-310 UKPN0-410
16 230-440V UKPN0-316 UKPN0-416
20 230-440V UKPN0-320 UKPN0-420
20 230-440V UKPN1-320 UKPN1-420
25 230-440V UKPN1-325 UKPN1-425
32 230-440V UKPN1-332 UKPN1-432
32 230-440V UKPN3-332 UKPN3-432
40 230-440V UKPN3-340 UKPN3-440
50 230-440V UKPN3-350 UKPN3-450
63 230-440V UKPN3-363 UKPN3-463
63 230-440V UKPN5-363 UKPN5-463
80 230-440V UKPN5-380 UKPN5-480
100 230-440V UKPN5-3100 UKPN5-4100
125 230-440V UKPN5-3125 UKPN5-4125
150 230-440V UKPN5-3150 UKPN5-4150


25A 3P 230V 440V Waterproof Rotary Isolator Switch IP65 IEC standard











Product Feature







1.Safe and reliable: terminals equipped with protective cover, VDE0106 standard, ensure the security of the fingers.



2. It has a variety of uses in industrial machinery and equipment. When used as a maintenance and insurance switch, for example, can be installed in part O 3 padlocks, in order to ensure the personal safety of users.



3. The application of flexible: 800 standard contact combination, almost unlimited combination switch.



4.It can be used reliably in lighting equipment,heating equipment and motors reliably,in addition,they also can switch the motor(AC-3) derectly,its high on-off ability can ensure the work reliability at frequently making and breaking.



5.Beautiful appearance,novel,simple,small size and function are the ideal choice among similar products.









Certification





25A 3P 230V 440V Waterproof Rotary Isolator Switch IP65 IEC standard







Packaging & Delivery



 Lead Time  Normally 20 days after received your fund, but mostly depends on   your quantity
 Leading Port  Ningbo or Shanghai by sea or by air. If any other loading port please   kindly advise and the extra inland transportation freight will be added   accordingly.
 Trade Term  EXW, FOB, CIF as customer need
 Payment Term  T/T 30% as deposit,and 70% before delivery.
 Packaging  Neutral carton, or according to customer requirements
 Shipping  By Air, by sea, by express







Service



1. Your inquiry and problems related to our products or prices will be replied in 24 hours;

2. Strong production capacity and strict quality control system;

3. Well-trained and experienced staffs to answer all your inquires;

4. After-sale tracking service for all of our clients;

5. OEM & ODM are available; there is an our own mould tooling center in KRIPAL factory.









Our company





Zhejiang kripal Electric Co., Ltd. is a national high-tech enterprise specializing in R & D, production and sales. Our products mainly include: small, molded case circuit breakers, AC contactors, building electrical, outdoor waterproof, control components, industrial plugs and sockets, etc.



The company was founded in 1992, after 30 years of vigorous development, the existing plant area of more than 15000 square meters, more than 500 employees, including over 10 senior engineers, 30 professional technicists and 30 senior executives. The products have passed the certificate of UL,VDE,TUV, Kema,Semko,SAA,CE and CB test report,also ROHS international certification, and obtained the national 3C, ISO9001 quality certification.



The company adheres to the enterprise policy of "management, independent innovation, coordination and cooperation, brand supremacy" and abides by the promise of "virtue in the world". Practice the core values of "win-win cooperation with customers, common prosperity with employees, benefit creation for the company and harmonious contribution to society", and strive for the mission of "strive to realize the dream of professional electrical world brand".



We sincerely welcome new and old customers at home and abroad to contact us and create a better future.
